Grinding   Turning

  • Electro-permanent radial pole circular chuck with reinforced holding force
  • Space between the poles filled with brass
  • For ring-shaped work pieces
  • Suitable for grinding and turning operations
  • Corresponding Control Unit and Remote Control to be ordered separately (see 50.03.BUP.400 / 50.03.BUP.230 and 50.10.T10)

Included with purchase:

  • Electric connection at the rear of the chuck
  • Slip ring assembly either integrated into the chuck or supplied separately (to be fitted to the machine spindle)

Normal force: 140 N/cm2

Admissible wear of top plate: 8 mm

Voltage: 340 VDC

Technical Drawing - Electro-Permanent Circular Magnetic Chuck type EPERC-N
CODE Weight Kg A B C D E F G H I J
11.15.200.8.340 24,0 200 100 - - - 4xM10 4 45 8 -
11.15.250.8.340 39,0 250 100 - - - 4xM12 4 65 8 -
11.15.300.12.340 54,0 300 100 - - - 4xM12 4 85 12 -
11.15.400.12.340 85,0 400 100 - - - 6xM12 5 100 12 -
11.15.500.16.340 150,0 500 110 - - - 6xM12 5 150 16 -
11.15.600.16.340 210,0 600 110 - - - 6xM16 5 180 16 -
11.15.700.16.340 280,0 700 110 - - - 6xM16 5 200 16 -
11.15.800.24.340 380,0 800 110 - - - 6xM16 5 200 24 -
11.15.1000.24.340 680,0 1000 125 - - - 8xM16 5 250 24 -
