  • 2 or 3 active faces
  • Without actuating mechanism
  • Available in Samarium version (see reference with "S"), holding force 180 N/cm2

Standard pole pitch: 4 mm

Pole pitch for model 13.23.4: 1.3 mm

Admissible wear of top plate: 5 mm

Parallelism: 0.05 mm

Technical Drawing - Circular Permanent Magnetic Chuck type MPF2
CODE Weight Kg A B C D E
13.23.1 3,2 100 100 50 1-100x100 + 2-100x50 80 daN
13.23.1S 3,2 100 100 50 1-100x100 + 1-100x50 180 daN
13.23.2 1,6 100 50 50 2-100x50 + 1-100x50 80 daN
13.23.2S 1,6 100 50 50 2-100x50 + 1-100x50 180 daN
13.23.3 0,4 100 25 25 2-100x25 80 daN
13.23.3S 0,4 100 25 25 2-100x25 180 daN
13.23.4 0,4 100 25 25 2-100x25 80 daN
