Neodymium permanent magnet

Discs

DISCS 10-13 MM

The Neodymium discs listed on this page have a standard magnetization degree of N35, with axial magnetization and nickel-coating.

Contact us to get quick feedback on prices, availability and customized products.
You can view and download the technical drawings of each product by clicking on the respective code, highlighted in blue.

All measures are in millimeters (mm).

CODE	TYPE	DIAMETER	H	STRENGTH KG
DN01.35NI00.100.5	SC35MANI	10	0,5	0,26
DN01.35NI00.101	SC35MANI	10	1	0,40
DN01.35NI00.101.5	SC35MANI	10	1,5	0,70
DN01.35NI00.102	SC35MANI	10	2	1,10
DN01.35NI00.102.5	SC35MANI	10	2,5	1,23
DN01.35NI00.103	SC35MANI	10	3	1,60
DN01.35NI00.104	SC35MANI	10	4	2,30
DN01.35NI00.105	SC35MANI	10	5	2,30
DN01.35NI00.106	SC35MANI	10	6	2,40
DN01.35NI00.107	SC35MANI	10	7	2,50
DN01.35NI00.108	SC35MANI	10	8	2,90
DN01.35NI00.1010	SC35MANI	10	10	3,00
DN01.35NI00.1012	SC35MANI	10	12	3,50
DN01.35NI00.1015	SC35MANI	10	15	3,60
DN01.35NI00.1018	SC35MANI	10	18	3,60
DN01.35NI00.1020	SC35MANI	10	20	3,40
DN01.35NI00.1023	SC35MANI	10	23	3,50
DN01.35NI00.1028	SC35MANI	10	28	3,88
DN01.35NI00.1030	SC35MANI	10	30	3,55
DN01.35NI00.1035	SC35MANI	10	35	3,90
DN01.35NI00.1040	SC35MANI	10	40	3,60
DN01.35NI00.1050	SC35MANI	10	50	3,61
DN01.35NI00.10.53	SC35MANI	10,5	3	2,36
DN01.35NI00.120.5	SC35MANI	12	0,5	0,30
DN01.35NI00.121	SC35MANI	12	1	0,65
DN01.35NI00.121.5	SC35MANI	12	1,5	1,00
DN01.35NI00.122	SC35MANI	12	2	1,25
DN01.35NI00.122.5	SC35MANI	12	2,5	1,58
DN01.35NI00.123	SC35MANI	12	3	1,80
DN01.35NI00.123.5	SC35MANI	12	3,5	2,16
DN01.35NI00.124	SC35MANI	12	4	2,40
DN01.35NI00.125	SC35MANI	12	5	3,20
DN01.35NI00.126	SC35MANI	12	6	3,65
DN01.35NI00.128	SC35MANI	12	8	3,73
DN01.35NI00.1210	SC35MANI	12	10	4,10
DN01.35NI00.1212	SC35MANI	12	12	4,92
DN01.35NI00.1215	SC35MANI	12	15	4,70
DN01.35NI00.132	SC35MANI	13	2	1,40
DN01.35NI00.133	SC35MANI	13	3	2,08
DN01.35NI00.135	SC35MANI	13	5	3,14
DN01.35NI00.136	SC35MANI	13	6	3,57
DN01.35NI00.138	SC35MANI	13	8	4,22
DN01.35NI00.1310	SC35MANI	13	10	4,70

The maximum standard operating temperature is 80 °C.
On request, we can supply magnets capable of operating at higher temperatures, as indicated in the Materials Table.

Many of these sizes are also available in other variants, with different coatings and degrees of magnetization.

The force values given in the tables are the result of dynamometric tests performed with a 10 mm thick iron plate.
Any variations from this standard in the use may change the actual performance of the magnet.

It is always recommended to perform specific tests according to your application.
